NU324 Cylindrical Roller Bearing 120x260x55mm Cylindrical Bearing
UPC: 00193019308073
Type: Cylindrical Roller Bearings
Size: 120mm x 260mm x 55mm
Dynamic load rating Cr:450 KN
Static load rating Cor: 510 KN
NU324 Cylindrical Roller Bearing
✔️ 120mm x 260mm x 55mm - Removable Inner Ring
The NU324 is a heavy-duty cylindrical roller bearing designed for high radial loads and precision alignment. With a removable inner ring and full chrome steel construction (52100 alloy), it's ideal for gearboxes, electric motors, and industrial machinery where disassembly and durability are essential.
✅ Type: Cylindrical roller bearing - NU configuration
✅ Inner Diameter: 120mm
✅ Outer Diameter: 260mm
✅ Width: 55mm
✅ Removable Inner Ring for easy mounting and dismounting
✅ Material: 52100 Chrome Steel
✅ Dynamic Load Rating (Cr): 450 kN
✅ Static Load Rating (Cor): 510 kN
✅ Pack Size: 1 bearing
Dimensions Table:
| Spec | Value |
|---|---|
| Inner Diameter | 120mm |
| Outer Diameter | 260mm |
| Width | 55mm |
| Dynamic Load | 450 kN |
| Static Load | 510 kN |
| Ring Type | Inner ring removable |
💡 What’s the benefit of an NU-style cylindrical roller bearing?
NU-style bearings allow axial displacement of the shaft relative to the housing, which is perfect for managing thermal expansion. The removable inner ring also simplifies installation and maintenance in heavy-duty systems.
Built to carry the load and built to last - install the NU324 in your machinery and roll with confidence under pressure!
