25mm Stroke Rotary Ball Bushing Bearing - Linear Motion

25mm Linear Stroke Rotary Ball Bushing - Smooth Linear Motion
✔️ 25mm ID x 37mm OD x 45mm Length - For 25mm Shafts

This 25mm linear bushing bearing is designed for guided rotary and linear motion along 25mm shafts. It offers smooth, low-friction movement with high load capacity, making it ideal for CNC machines, automation rails, and precision-guided equipment.

✅ Type: Linear ball bushing bearing
✅ Inner diameter (ID): 25mm
✅ Outer diameter (OD): 37mm
✅ Length: 45mm
✅ Max stroke: 28mm
✅ Dynamic load rating Cr: 240 KGF
✅ Static load rating Cor: 300 KGF
✅ Compatible shaft size: 25mm
✅ Quantity: 1 bearing

💡 What’s the benefit of combining rotary and linear motion in one bushing?
Rotary linear bushings allow both smooth sliding and shaft rotation, ideal for complex automation setups that require synchronized axial and radial motion in a single compact assembly.

Precision movement, dual-axis capability - built for advanced motion control on 25mm shafts.
