NA4900 Needle Roller Bearing 10x22x13mm - Machined Type
UPC: 00193019067451
Type: Needle Roller Bearing
Dimensions: 10mm x 22mm x 13mm/Metric
ID (inner diameter)/Bore: 10mm
OD (outer diameter): 22mm
NA4900 Needle Roller Bearing
✔️ 10mm ID × 22mm OD × 13mm Wide - Machined Type - Inner Ring Included
The NA4900 is a high-precision machined needle roller bearing built for compact, high-load applications. With a 10mm inner diameter and a complete inner ring (cone), this bearing offers excellent radial load capacity while maintaining a low cross-section - ideal for gearboxes, transmissions, and automation systems.
✅ Inner diameter (ID): 10mm
✅ Outer diameter (OD): 22mm
✅ Width: 13mm (inner and outer ring)
✅ Type: Machined needle roller bearing
✅ Complete assembly: Includes inner ring (cone)
✅ Dynamic load rating: 940 KGF
✅ Static load rating: 1,030 KGF
✅ Material: High-strength alloy steel
✅ Brand: VXB Bearing
✅ Quantity: 1 bearing
Dimensions Table (mm):
| ID | OD | Width | Dynamic Load (KGF) | Static Load (KGF) |
|---|---|---|---|---|
| 10mm | 22mm | 13mm | 940 | 1,030 |
💡 Why choose machined needle roller bearings like the NA4900?
Machined needle bearings offer precise alignment, high load capacity, and compact size. Their solid inner and outer rings make them ideal for demanding applications where space is limited but strength is critical.
Slim, strong, and built to last - upgrade with the NA4900 and keep your motion system lean and powerful!
