80TAH10TDB Nachi Thrust Angular Contact Bearing 80x125x40.5 ABEC 7
80TAH10TDB Nachi Thrust Angular Contact Bearing 80x125x40.5 ABEC 7
80TAH10TDB Nachi Thrust Angular Contact Bearing 80x125x40.5 ABEC 7
Nachi

80TAH10TDB Nachi Thrust Angular Contact Bearing 80x125x40.5 ABEC 7


$3,443.43 CAD $4,648.63 CADyou save $1,205.20 CAD
SKU: Kit13566
UPC: 00193019096505
Item: 80TAH10TDB Nachi Ball Bearing
Type: Nachi Angular Spindle Ball Bearing
Cage: Phenolic resin
Dimensions: 80mm x 125mm x 40.5mm/Metric
ID (inner diameter)/Bore: 80mm

80TAH10TDB Nachi Thrust Load Angular Contact Ball Bearing
30 degrees Contact Angle
Abec-7
Made in Japan

80TAH10TDB Nachi Thrust Load Angular Contact Ball Bearing, Ball Bearing is Super precision Angular with 30 degrees contact angle, bearing is ABEC-7 quality and made in Japan.

  • 80TAH10TDB Nachi Ball Bearing
  • Palier à billes à broche angulaire Nachi
  • Cage : Résine phénolique
  • Dimensions: 80mm x 125mm x 40.5mm/Metric
  • DIJ (diamètre intérieur)/Alésage : 80 mm
  • Diamètre extérieur (diamètre extérieur) : 125 mm
  • Width: 40.5mm
  • Size: 80 x 125 x 40.5 mm
  • Quantité : 1 roulement
  • Charge dynamique Cr : 41 500 N
  • Static load rating Cor: 99,500 N
  • Limitation de la vitesse :
    • Grease Lubrication: 7300 RPM
    • Oil Lubrication: 9200 RPM
  • Fabriqué au Japon
