12mm x 4mm Press Fit Plastic Spring Ball Plunger - POM Ball
UPC: 00193019347621
12mm x 4mm Press Fit Plastic Spring Ball Plunger with POM Ball
✔️ Blue POM Body with Non-Metallic Ball for Light Load Applications
This 12mm x 4mm press fit plastic ball plunger is designed for soft-surface and non-metal builds where light holding force and non-scratch contact are needed. With a blue POM body and a plastic POM ball backed by a stainless steel spring, it’s perfect for furniture joints, fixture guides, and delicate panel assemblies.
âś… Diameter: 12mm
âś… Length: 4mm
âś… Body: Blue POM (Polyoxymethylene)
âś… Ball: POM (Plastic)
âś… Spring: Stainless Steel
âś… Ball Protrusion (S): 0.6mm
âś… Ball Height (e): 1.0mm
âś… Load Rating: 1.7N to 3.6N
âś… Press-fit style for simple, thread-free install
Dimensions (mm):
| Parameter | Value |
|---|---|
| D (Ball) | 12.0 |
| d (Body OD) | 10.0 |
| D1 (Head OD) | 12.5 |
| L (Body Length) | 4.0 |
| S (Protrusion) | 0.6 |
| e (Ball Height) | 1.0 |
| Load (N) | 1.7-3.6 |
💡 What’s the benefit of using press-fit plastic ball plungers for fixture setups?
Plastic plungers protect components while keeping alignment steady.
-
Gentle contact that won’t damage soft plastic or wood parts
-
Easy snap-in install, no threading, no hassle
-
Great for assemblies that require quick adjustability
-
Non-metallic body prevents corrosion and noise
If you’re working on a clean, low-friction build with delicate components, this one keeps things steady without scratching, order now and get the smooth finish your setup needs!
