Nachi

5313 Nachi 2 Rows Angular Contact Bearing Japan 65x140x58.7 Bearings


$641.54 CAD
SKU: Kit10071
UPC: 00193019085745
Item: 5313 Nachi Ball Bearing
Type: Nachi Double Row Angular Ball Bearing
Closures: Open
Dimensions: 65mm x 140mm x 58.7mm/Metric
ID (inner diameter)/Bore: 65mm

5313 Nachi Angular Ball Bearing
65mm x 140mm x 58.7mm
Made in Japan

5313 Nachi Double Row Angular Ball Bearing, Made in Japan, inner diameter is 65mm, outer diameter is 140mm and width is 58.7mm.

  • Item: 5313 Nachi Ball Bearing
  • Type: Nachi Double Row Angular Ball Bearing
  • Closures: Open
  • Dimensions: 65mm x 140mm x 58.7mm/Metric
  • ID (inner diameter)/Bore: 65mm
  • OD (outer diameter D1): 140mm
  • Width/Height/thickness: 58.7mm
  • Size: 65 x 140 x 58.7 mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 145,000 N
  • Static load rating Cor: 115,000 N
  • Limiting Speed:
    • Grease Lubrication: 3,600 RPM
    • Oil Lubrication: 4,700 RPM
  • Made in Japan

The construction of this type ball bearing is similar to the adjacent, BACK-TO-BACK mounting of two Single-row Angular Contact ball bearings. Because fewer balls can be inserted per row compared to Single-row Angular Contact ball bearings, a Double-row Angular Contact ball bearing will have less load capacity than an equivalent size/series BACK-TO-BACK set of two Single-row Angular Contact ball bearings. This bearing type can sustain radial, moment and bi-directional axial loads.
