Nachi

6219-2NSE Nachi Bearing Sealed C3 Japan 95x170x32


$325.70 CAD
SKU: Kit9720
UPC: 00193019103531
Item: 6219-2NSE Nachi Ball Bearing
Type: Nachi Deep groove Ball Bearing
Closures: Double sealed rubber seals RS/RS1/2RS1
Radial Clearance: C3
Dimensions: 95mm x 170mm x 32mm/Metric

6219-2NSE Nachi Bearing
95mm x 170mm x 32mm
Made in Japan


6219-2NSE Nachi Bearing, Made in Japan, the 6219-2NSE inner diameter is 95mm, the 6219-2NSE outer diameter is 170mm, 6219-2NSE width is 32mm.

  • Item: 6219-2NSE Nachi Ball Bearing
  • Type: Nachi Deep groove Ball Bearing
  • Closures: Double sealed rubber seals RS/RS1/2RS1
  • Radial Clearance: C3
  • Dimensions: 95mm x 170mm x 32mm/Metric
  • ID (inner diameter)/Bore: 95mm
  • OD (outer diameter): 170mm
  • Width/Height/thickness: 32mm
  • Size: 95 x 170 x 32 mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 122000 N
  • Static load rating Cor: 93000 N
  • Limiting Speed:
    • Grease Lubrication: 2400 RPM
  • Equal: 6219 RS / 6219 2RS
  • Made in Japan

Advanced Seal Design Provides
Excellent Protection and Smooth Operation

The combination of a unique lip design and seal groove provides a labrinth and steady seal contact.Breathing mechanism avoids torque increases caused byinternal pressure variation due to changes in operating temperatures.NSE seals allow NACHI bearings to have constant smooth operation and long service life.

  • Superior in Sealing Out Dust, Dirt, and Contamination
  • Superb Grease Retention
  • Light Torque
    The Best Components Yield the Greatest Bearing Performance
    Rings and balls made of select material have superbly controlled accuracy such as roundness, contour,surface finish, and hardness to provide quieter operation, reduced vibration levels, and long life.Rivet-type pressed steel cages for strength and durability.High-performance grease for long life and low noise.


  •
