Nachi

7214CYP5 Nachi Angular Contact Bearing 70x125x24 Abec-5 Japan


$611.93
SKU: Kit10818
UPC: 00193019091173
Item: 7214CYP5 Angular Ball Bearing
Type: Nachi Angular Ball Bearing
Dimensions: 70mm x 125mm x 24mm/Metric
Bearing Inner Diameter: 70mm
Bearing Outer diameter: 125mm

7214CYP5 Nachi Angular Abec-5 Ball Bearing
15 Contact Angle
Polyamide resin cage
70mm x 125mm x 24mm
Made in Japan







7214CYP5 Nachi Angular Ball Bearings, 15 Contact Angle, Polyamide resin cage, Abec-5 Made in Japan, here are the dimensions of the 7214CYP5, the 7214CYP5 inner diameter is 70mm, the 7214CYP5 outer diameter is 125mm, 7214CYP5 width is 24mm.

  • Item: 7214CYP5 Angular Ball Bearing
  • Type: Nachi Angular Ball Bearing
  • Dimensions: 70mm x 125mm x 24mm/Metric
  • Bearing Inner Diameter: 70mm
  • Bearing Outer diameter: 125mm
  • Bearing Width: 24mm
  • Cage: Polyamide resin cage
  • Quality: ABEC-5
  • Size: 70mm x 125mm x 24mm
  • Made in Japan
  • Quantity: One Bearing
d D B r r1
70mm 125mm 24mm 1.5 1

The raceways of both the inner and outer rings of this bearing type are made with a set contact angle. These bearings are non-separable. Since the balls are inserted utilizing counter-bore construction, a larger number of balls can be installed than in the case of Deep-groove ball bearings. Standard cage materials may be pressed steel, high-strength brass, or synthetic resin. Cage material is dependent on the bearing series and or service condition. Single-row Angular Contact ball bearings can sustain radial, axial or composite loads, however, any axial load must be in one direction. This bearing type is generally used in pairs to handle the induced load resulting from the internal axial force generated by the applied radial load. When mounting two single bearings in adjacent positions, NACHI provides these combination parts (pairs) with preadjusted clearance. Paired combination bearings are matched sets. Combination or paired bearings can be arranged BACK-TO-BACK (DB), FACE-TOFACE (DF), or in TANDEM (DT). DB or DF sets can sustain bidirectional axial loads.
