7.5 HP AC industrial motor single unit, 208-230/460V 3-phase 60Hz, 3500 RPM, 184JM frame, F1 foot mount, OPSB enclosure, 1.15 service factor, NEMA Design B, sealed ball bearing, 90.2% efficiency

Single unit 7.5 HP 3-Phase AC Motor, 208-230/460V, 3500 RPM
✔️ 184JM frame, F1 foot mount, OPSB enclosure, 1.15 SF, 90.2% eff

This single industrial AC motor is a 7.5 HP, 3-phase unit built for pumps, compressors, blowers and conveyor drives in factories and processing plants. It fits standard foot-mounted installations and replaces common OEM units.

✅ Catalog: EJMM3219T, Spec 36G687X419, Elec Spec 36WGX419
✅ Power: 7.5 HP, 208-230/460V, 60Hz, 3-phase; 18.5-16.8/8.4 FLA
✅ Speed: 3500 RPM; usable at 208V: 18.5A
✅ Frame & mount: 184JM frame, F1 foot mount, RG base, OPSB enclosure
✅ Bearings: DE 6207, ODE 6205; sealed ball bearing support
✅ Performance: 1.15 service factor, 40C amb-cont rating, NEMA Design B
✅ Electrical: Insulation Class F, Locked rotor code K, 90.2% efficiency, PF 0.93
✅ Mechanical: Type 3646M designation, base RG, mounting F1

💡 Why choose sealed ball bearing motors for heavy-duty drives? Sealed bearings cut maintenance and keep uptime high. Here’s a quick intro, then handy, scan-friendly points to help SEO and buying decisions. - Reduced maintenance and better contamination resistance, handy for dusty or washdown areas - Longer bearing life and steady performance under 40C ambient-continuous rating - Better thermal stability with Insulation Class F and high full load efficiency - Easy swap-in replacement for standard 184JM frame foot-mounted motor applications
