BNH013TU Nachi Angular Contact Spindle Bearing 65x100x18 ABEC 7
UPC: 00193019092194
Type: Nachi Angular Spindle Ball Bearing
Cage: Phenolic cage
Quality: ABEC-7
Dimensions: 65mm x 100mm x 18mm/Metric
| High Precision Ball Bearing BNH013TU Nachi High Speed Angular Spindle Ball Bearing 15 degrees Contact Angle Abec-7 65mm x 100mm x 18mm Made in Japan |
|
BNH013TU Nachi High Speed Angular Spindle Bearing, Ball Bearing is Super precision Angular with 15 degrees contact angle and Phenolic cage, Bearing is ABEC-7 quality and made in Japan. BNH013TU inner diameter is 65mm, BNH013TU outer diameter is 100mm, BNH013TU width is 18mm.
|
|||||||||||||||||||
The raceways of both the inner and outer rings of this bearing type are made with a set contact angle. These bearings are non-separable. Since the balls are inserted utilizing counter-bore construction, a larger number of balls can be installed than in the case of Deep-groove ball bearings. Standard cage materials may be pressed steel, high-strength brass, or synthetic resin. Cage material is dependent on the bearing series and or service condition. Single-row Angular Contact ball bearings can sustain radial, axial or composite loads, however, any axial load must be in one direction. This bearing type is generally used in pairs to handle the induced load resulting from the internal axial force generated by the applied radial load. When mounting two single bearings in adjacent positions, NACHI provides these combination parts (pairs) with preadjusted clearance. Paired combination bearings are matched sets. Combination or paired bearings can be arranged BACK-TO-BACK (DB), FACE-TOFACE (DF), or in TANDEM (DT). DB or DF sets can sustain bidirectional axial loads.
