BTM205-15 15/16 in (24.0 mm) Narrow Inner-Ring Flanged Ball Bearing Insert, 3-Bolt Flange, Malleable Iron Housing, Set-Screw Lock, Contact Seal, 5/16 in (7.9 mm) Bolt Size, 1/4-28 UNF Grease

Single 3-bolt flange ball bearing insert 15/16 in (24.0 mm) I.D.
✔️ Malleable housing; set-screw lock; 15/16 in (24.0 mm) I.D.

This single BTM205-15 flanged bearing insert is a narrow inner-ring, set-screw locked ball bearing in a malleable iron TM205 housing. It’s commonly used on conveyors, motors, agricultural equipment and linear slide unit mounts where a sealed ball bearing with relubrication is needed.

✅ Model: BTM205-15
✅ Inner diameter: 15/16 in (24.0 mm)
✅ Inner ring width: Narrow
✅ Housing: Malleable iron, TM205 style
✅ Bolt pattern: 3-bolt flange; bolt size 5/16 in (7.9 mm)
✅ Insert: Ball bearing, bearing steel
✅ Locking: Set-screw type
✅ Seal: Contact seal for contamination protection
✅ Lubrication: 1/4-28 UNF grease fitting (1/4 in = 6.35 mm), relubricatable
✅ Duty & temp: Standard duty; high temp to 212°F (100°C)
✅ HTS code: 8483.20.40.40; weight: 0.720 lb (0.327 kg)

💡 What is a flanged ball bearing insert used for in conveyor and linear slide applications? A flanged ball bearing insert mounts a shaft quickly and gives reliable, sealed support in many industrial setups. Short intro: these inserts make maintenance easy and protect shafts from dirt and moisture. - Supports radial loads and aligns shafts for smooth operation in conveyors, motors, and linear slide unit systems - Sealed ball bearing design with contact seals and relubrication keeps contaminants out and extends service life - Malleable iron flanged housings like TM205 allow straightforward 3-bolt mounting and quick insert replacement
