CS-14 Φ73mm Harmonic Drive Gear Ratio 30:1 - Strain Wave Gear Reducer

CS-14 Strain Wave Gear Reducer, Φ73mm Harmonic Drive Gear Ratio 30:1
✔️ Compact Harmonic Gear for Accurate Motion Control

The CS-14 strain wave gear reducer with a 30:1 ratio is built for smooth and accurate motion control in robotics, automation equipment, and servo-driven positioning systems where steady torque and low backlash are important.

✅ Gear ratio: 30:1
✅ Outer diameter: Φ73mm
✅ Rated torque at 2000 rpm: 4 Nm
✅ Limit for repeated peak torque: 9 Nm
✅ Limit for average torque: 6.8 Nm
✅ Limit for momentary peak torque: 17 Nm
✅ Maximum input speed: 8500 rpm
✅ Limit for average input speed: 3500 rpm
✅ Backlash: ≤20 arcsec

💡 What is a strain wave gear reducer used for in motion control systems?
Strain wave gear reducers are used to deliver accurate positioning and smooth torque transfer in compact mechanical assemblies.

- Helps maintain precise angular positioning under load
- Keeps motion smooth with controlled backlash levels
- Supports compact layouts in servo and robotic designs

This 30:1 CS-14 harmonic reducer is a handy choice for controlled motion where space and accuracy matter.
