CUCFC216CE Piloted Flange Cartridge, 80 mm Wide Inner Ring Ball Bearing Insert with Set-Screw Lock, Cast-Iron Housing with Closed Cover, M20 Bolt, 1 pc, 1/8-27 NPT Grease

80 mm Piloted Flange Cartridge - Wide Inner Ring
✔️ Single unit, 80 mm ID, wide inner ring, M20 bolt, set-screw

This is a single piloted flange cartridge bearing unit with a wide inner ring and closed cast-iron cover, ideal for industrial shafts and conveyor systems. It features a sealed ball bearing insert ready for relubrication and fits standard piloted flange mounts.

✅ I.D.: 80 mm (wide inner ring)
✅ Insert type: ball bearing, bearing steel
✅ Locking: set-screw on inner ring
✅ Housing: cast iron CFC216; covers: 1 open, 1 closed cast iron
✅ Bolt size: M20; lubrication fitting: 1/8-27 NPT; relubrication: yes
✅ Seal: contact seal with slinger; max temp ~212 F; HTS 8483.20.40.40

💡 What is a piloted flange bearing cartridge used for? Piloted flange cartridges are handy for mounting and supporting rotating shafts where precise alignment and easy replacement are needed. - Common in conveyor drives, reducers, and industrial gearboxes; works with sealed ball bearing inserts - Used on linear slide unit setups and shaft support points needing relubrication access - Often chosen over ceramic inserts when toughness and standard steel bearing performance are required
