Flanged Sleeve Bearing Brass With Graphite Self Lubricating Oilless Wrapped Bushings 5mm Bore 7mm Outer Diameter 8mm Length Flange Diameter 11mm Flange Thickness 2mm 2 Pieces For High Load Applications And Maintenance Free Operation

Brass Flanged Sleeve Bearings, 5mm Bore, 7mm OD, 2 pcs
✔️ Bore 5mm, OD 7mm, Length 8mm, Flange 11mm dia, 2mm thick (2 pcs)

These compact bearing sleeves act as plain bushings that guide shafts with low friction in linear motion. Made from cast brass and graphite, they are self-lubricating and ideal for compact equipment like printers, electrical gear, and machine tools.

✅ Bore diameter: 5 mm
✅ Outside diameter: 7 mm
✅ Length: 8 mm
✅ Flange diameter: 11 mm
✅ Flange thickness: 2 mm
✅ Material: Cast brass with graphite self-lubrication
✅ Pack size: 2 pcs

💡 What is a brass flanged sleeve bearing used for in linear motion systems?

They’re handy for guiding and reducing friction in compact equipment where dry lubrication is desired.

- Handy for low-maintenance guides in printers, electrical gear, and small machines
- Reduces shaft wear by providing smooth sliding action in rotating or linear axes
- Easy to install with a press-fit and optional locking screws
- Suitable for higher temperature and corrosive environments thanks to brass graphite composition
