HD Mini-08 40mm Harmonic Drive Gear Ratio 30:1 - Strain Wave Gear Reducer

HD-08 Harmonic Gear Reducer 30:1

✔️ Compact Strain Wave Gear for Precision Motion Control

The HD-08 30:1 harmonic gear reducer is designed for compact motion systems that require stable torque output, smooth operation, and accurate positioning. Using only the published performance parameters, this reducer supports reliable motion control at moderate torque levels with low backlash.

✅ Gear ratio: 30:1
✅ Rated torque at 2000 rpm: 0.8 Nm
✅ Limit for repeated peak torque: 1.6 Nm
✅ Limit for average torque: 1.3 Nm
✅ Limit for momentary peak torque: 3.2 Nm
✅ Maximum input speed: 8,500 rpm
✅ Limit for average input speed: 3,500 rpm
✅ Backlash: ≤20 arcsec
✅ Delivery time 10 to 15 days

💡 What applications use a 30:1 harmonic gear reducer?
A 30:1 harmonic reducer is commonly used in compact robotics, automation equipment, and precision actuators where smooth motion and controlled torque are required.

This 30:1 model offers a balanced mix of speed and torque for precision-motion applications.
