HD-11 Pro Harmonic Gear Reducer 50:1

✔️ Pro-Series Strain Wave Gear for Precision Motion Control

The HD-11 Pro 50:1 harmonic gear reducer is designed for compact precision motion systems that require smooth output, reliable torque handling, and controlled backlash. Using only the table specifications, this Pro version delivers stable performance for robotics, automation, and servo driven applications.

✅ Gear ratio: 50:1
✅ Rated torque at 2000 rpm: 4.5 Nm
✅ Limit for repeated peak torque: 13 Nm
✅ Limit for average torque: 6.8 Nm
✅ Limit for momentary peak torque: 25 Nm
✅ Maximum input speed: 8500 rpm
✅ Limit for average input speed: 3500 rpm
✅ Moment of inertia: 0.021 x10^4 kgm^2
✅ Backlash: ≤20 arcsec
✅ Delivery time 10 to 15 days

💡 Why choose a Pro series harmonic gear reducer for compact servo systems?

Pro series harmonic reducers are tuned for smoother operation and tighter performance consistency in compact servo driven motion systems.

This 50:1 Pro version delivers clean motion control with dependable torque in space-limited applications.
