Heavy Duty Hoist Ring 5/8-11 ADB Safe Rigging Hardware Corrosion-Resistant Finish ASME B30.26 Compliant Threaded Stud Design For Quick Install And Reliable Lifting On Job Sites For Heavy Lifting Projects

Heavy-Duty 5/8-11 ADB Hoist Ring, American Made, Single Unit
✔️ 5/8 in dia, 11 TPI, WLL 4000 lb, MIL-STD 209, USA made

Compact and rugged, the American-made ADB hoist ring offers a secure lifting point for heavy loads on job sites, cranes, and rigging setups. The 5/8" threaded stud and forged alloy steel body provide strong, reliable performance with a corrosion-resistant black oxide finish. This hardware is designed to meet ASME B30.26 and MIL-STD 209 standards for safety and longevity.

✅ 5/8 in diameter, 11 TPI
✅ Working Load Limit: 4000 lb
✅ Forged high-strength alloy steel with black oxide finish
✅ Magnetic Particle Inspect per ASTM E1444
✅ Minimum Design Factor: 5:1
✅ Rate applies 0-90 degrees from bolt axis; constant load
✅ ANSI/ASME B30.26 and MIL-STD 209 compliant
✅ Part No. 33615; Made in USA

💡 What is a heavy-duty hoist ring used for in lifting operations?

A handy, anchor point for lifting and rigging that helps move heavy loads safely.

- Used in cranes, hoists, and rigging to attach slings, hooks, and shackles - Maintains rated load across 0 to 90 degrees with a 5:1 design factor - Forged alloy steel with black oxide finish provides corrosion resistance - Meets ANSI/ASME B30.26 and MIL-STD 209 for reliable performance
