Heavy Duty Hoist Ring Seven Eighths Inch 9 UNC Threaded Stud Lift Point

Heavy Duty 7/8 in Hoist Ring with 9 UNC Stud, 8000 lb WLL
✔️ 7/8 in diameter, 9 UNC thread, 8000 lb working load, single unit

This heavy-duty hoist ring uses a threaded stud design for quick, secure installation and is built to handle demanding lifts up to 8000 lb WLL. Manufactured in the USA by American Drill Bushing, it features a corrosion-resistant black oxide finish to extend service life and is ideal for rigging in manufacturing, construction, and maintenance environments.

✅ 7/8 inch diameter hoist ring with 9 UNC threads
✅ Working Load Limit: 8000 pounds
✅ Forged high-strength alloy steel with black oxide finish
✅ Minimum design factor: 5:1
✅ Magnetic Particle Inspect (ASTM E1444) performed
✅ Meets MIL-STD 209 and ANSI/ASME B30.26
✅ Made in USA, ADB Part No. 33101

💡 What is a heavy-duty hoist ring with a threaded stud used for in lifting and rigging operations? This handy lifting point provides a secure, load-rated connection for overhead lifts and slings.
- High load capacity up to 8000 lb
- Quick, secure installation with 9 UNC threaded stud
- Corrosion-resistant black oxide finish for longer life
- Meets MIL-STD 209 and ANSI/ASME B30.26 safety standards
