Nexen 801510, Split-Hub/Collar Mount Air Engaged Torque Limiter

Nexen 801510 TL-AC Air-Engaged Torque Limiter - Collar Mount, 1.125 in Bore, 2150 in-lb Max
✔️ Air-engaged torque limiter with collar mount, 1.125 in bore, 2150 in-lb max.

The Nexen 801510 TL-AC is an air‑engaged, shaft‑mounted torque limiter designed to protect gear trains and tooling by clamping torque to a preset value. With a 1.125 in bore and a collar‑mount configuration, it fits compact power transmissions found on conveyors, presses, and automated machinery, providing reliable protection around a full 360° of the shaft.

✅ Max static clutch torque: 2150 inlbs
✅ Min static clutch torque: 510 inlbs
✅ Bore size: 1.125 in
✅ Engagement positions: 1 at 360°
💡 What is an air-engaged torque limiter used for in shaft-powered machinery and how does a collar-mount TL-AC unit protect a drive? Here’s a quick overview. - Overload protection by slipping at a preset torque during startup or peak load - Shaft-mounted collar-mount design for compact installations around the full shaft - 1.125 in bore compatibility with TL-AC collar mounts and a single engagement position - Torque range of 510-2150 in-lbs provides precise, repeatable protection This setup helps keep conveyors and presses safe, smooth, and reliable during peak loads.
