Premium Nema 34 Planetary Gearbox for Stepper Motors
✔️ 86mm housing with ratios 3:1 to 10:1, 14mm input, IP65 protection, and 60dB noise level

This planetary gearbox is a reliable reducer for Nema 34 stepper motors, commonly used in industrial automation, robotics, and CNC machines to boost torque and control speed effectively.

✅ Input options: 12.7mm or 14mm for easy integration
✅ Output shaft: 16mm or 14mm, with rated torque up to 60Nm
✅ Speed: Up to 3000 RPM input, precision less than 18 arcmin
✅ Construction: 20Cr carbon steel gears, drip-proof and IE1 efficiency

💡 How can a planetary gearbox improve precision in motion control systems?
This setup helps by stepping down motor speed while increasing torque for smoother operations.
- Enhances accuracy in high-load applications like robotics
- Reduces backlash for better positioning in automated systems
- Offers compact design to fit into tight spaces easily
- Boosts overall system reliability with IP65 protection
