PTI WS209 27U Wide Slot Take Up Bearing One And Eleven Sixteenths Inch Shaft Size WS 200 Silver Series Normal Duty For Heavy Machinery And Conveyor Systems Rugged Beefed Up Industrial Grade Performance

WS209 27U Wide Slot Take-Up Bearing with 1.69in Shaft
✔️ Single bearing unit, WS209, 27U wide slot, heavy-duty inline fit

This rugged WS209 take-up bearing is designed for heavy machinery and conveyor systems that demand solid support and precise shaft alignment. It features a 27U wide slot and a 1.69 in shaft to handle high loads in industrial environments.

✅ Shaft size d = 1.69 in (42.9 mm)
✅ Overall length a = 144.0 mm (5.67 in)
✅ Housing thickness b = 35.1 mm (1.38 in)
✅ Overall width d = 117.1 mm (4.61 in)
✅ Width between slots e = 102.1 mm (4.02 in)
✅ Slot length f = 82.6 mm (3.25 in)
✅ Length thru pilot hole g = 16.0 mm (0.63 in)
✅ Centerline to base of housing h = 87.1 mm (3.43 in)
✅ Pilot hole diameter k = 27.9 mm (1.1 in)
✅ Length thru bore including housing l = 47.8 mm (1.88 in)
✅ Tightening slot length m = 19.1 mm (0.75 in)
✅ Tightening slot width o = 49.0 mm (1.93 in)
✅ Base width p = 83.1 mm (3.27 in)
✅ Diameter at pilot hole r = 49.0 mm (1.93 in)
✅ Slot width s = 17.5 mm (0.69 in)

💡 What is a pillow block bearing used for in industrial drive systems?

In general, it's used to support rotating shafts in conveyors and machinery, keeping alignment and reducing wear under heavy loads.

• pillow block bearing supports shafts around 1.69 inches and wide slot
• sealed ball bearing design helps resist dust and grime
• mounts quickly with standard slot and bolt patterns
• ideal for heavy duty conveyor and material handling setups
