Worm Gear Speed Reducer 5:1 Ratio with 18mm Output Shaft for NEMA34

NMRV040 Worm Gear Speed Reducer 5:1 with 18mm Output Shaft
✔️ Right Angle Gearbox for NEMA34 Stepper and Servo Motors

This worm gear speed reducer is built to lower motor speed and boost torque in automation and machinery where compact right angle drive is needed. It is commonly used with stepper and servo motors in conveyors, processing equipment, and positioning systems. Pack size is one gearbox.

✅ Model: NMRV040 worm gear reducer
✅ Speed ratio: 5:1
✅ Input flange: NEMA34
✅ Input bore: 14 mm 0.55 inch
✅ Output bore: 18 mm 0.7 inch
✅ Housing material: aluminum alloy
✅ Worm gear material: ductile cast iron
✅ Worm shaft material: hardened alloy steel
✅ Protection rating: IP55 dust and moisture resistant
✅ Designed for high torque and stable transmission
✅ Low noise operation for continuous duty
✅ Used with stepper motors and servo motors
✅ Quantity: 1 gearbox

💡 Why choose a 5:1 worm gear reducer for stepper and servo motor drive systems?
It is used when moderate speed reduction and higher torque are needed in a compact right angle layout.

• Worm gear design converts high speed input into controlled low speed output

• Reduction ratio increases usable torque without complex gear trains

• Enclosed housing protects gears from dust and moisture

• Stable mesh geometry helps keep motion smooth under load

This gearbox is a handy choice when you need dependable torque increase and smooth speed control in motor driven equipment.
